Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal

    Buy cheap Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal from wholesalers

    Buy cheap Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal from wholesalers
    • Buy cheap Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal from wholesalers

    Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal

    Ask Lasest Price
    Brand Name : HUAHAI LASER
    Model Number : HM-06G
    Certification : CE , FDA
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 200sets per month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal

    6W 532nm Super Precise Green Laser Marking Priting Engraving Machine For Metal And Non-metal


    Product Introduction


    The green laser marking machine is suitable for surface processing and coating of most metal and non-metallic materials. Such as hardware, ceramics, glasses and clocks, PC, electronic devices, all kinds of instruments, PCB boards and control panels, nameplate panels, plastics, etc.; suitable for glass, crystal surface and internal engraving, such as mobile phone screen, LCD screen, optical device , car glass, etc. It is specially adapted to surface treatment such as marking and engraving of high flame retardant materials.

    Application
    Electronic Spare Parts, IC (Integrate Circuit), Electric Appliance, Moblie& Communication, Hardware, Tool Parts, Precision Apparatus, Glasses& Watch, Jewelry, Auto Parts, Plastic& Rubber keyboard, Building Materials, PVC, Medical Equipments and etc.
    ABS Materials (Appliance Housing, Commodity), PVC, Plastic, Glass, Metal and Alloy (Iron, Copper, Aluminum, Magnesium, Zinc etc), Rare metal and Alloy (Gold,Silver,Titanium), etc

    Main Feature


    1. Stable power output, superior beam quality, making marking more precise and higher definition;
    2, Semi-cold light source, small heat affected area;
    3, A wide range of applicable materials, to make up for the problem of many materials using fiber laser marking is not delicate enough.


    Technical Parameters


    SPECIFICATIONS FOR GREEN LASER MARKING MACHINE
    Laser power6w10w
    Laser wavelength532nm532nm
    Laser beam Quality (M2)<1.5<1.5
    Laser repetition frequency≤50KHz≤50KHz
    Standard engraving range100×100 mm100×100 mm
    Optional engraving range50×50--250×250 mm
    Engraving depth≤0.1mm≤0.1mm
    Engraving speed≤20000mm/s
    Minimum line width0.015mm0.025mm
    Minimum character0.2mm0.2mm
    Repeatability±0.001mm
    Power consumption of the whole machine1.5KW2.0KW
    Voltage220V/single phase/50Hz/10A

    Samples Show


    Super Precise Green Laser Marking Machine Water Cooling For Metal / Non - MetalSuper Precise Green Laser Marking Machine Water Cooling For Metal / Non - Metal
