    150W 3D Dynamic CO2 Laser Marking Machine For Invitation Card Shoes Soles Leather

    Ask Lasest Price
    Brand Name : Huahai Laser
    Model Number : RF-HB
    Payment Terms : T/T
    Delivery Time : 7-10 working days
    Certification : FDA , CE
    Price : Negotiable
    • Product Details
    • Company Profile

    150W 3D Dynamic CO2 Laser Marking Machine For Invitation Card Shoes Soles Leather

    150W 3D Dynamic Focus RF CO2 Laser Lazer Marking Engraving Cutting Machine for Invitation Card Shoes Soles Leather


    Product Description


    The CO2 Dynamic Laser Marking Machine is used of laser beam hollowing out process on varieties of surface of greeting
    card.


    The principle of hollowing out performance is via laser beam Evaporating and gasifying the surface of material, or laser can cause chemical and physical changes on surface material to achieve hollowing performance.


    1. High marking speed: maximum 7000mm/s marking speed with high-speed galvanometer scanning. Suitable for industrial mass production.
    2. Large marking area: Max marking area 800*600mm ,can realize marking, punching, cutting, carving process.
    3. Good stability of the equipment: Adopted the full closed optical path, imported of CO2 R.F laser source, strict multiple protection control design, ensure the stability of the entire equipment.
    4. Easy-operated of the equipment: the special control software is compatible with AutoCAD, CorelDRAW, Photoshop and other software, can realize the automatic arrangement and modify of text symbols, graphics, bar codes, two-dimensional

    code, sequence number is automatically incremented and decreasing, support PLT, PCX, DXF, BMP, JPG and other file
    formats, and TTF font can be used directly.
    Application: wood processing, leather processing, shoes & insole processing, jeans processing, invitation & greeting card
    processing, marble processing, LGP dotting processing for LED panel light and TV, LCD;

    Machines structure


    CO2 Dynamic Laser Marking Machine adopts imported laser tube and high speed galvo scanner, self-developed linear 3D Dynamic Focusing System, device control system, self-developed Control software and the high precision thermostatic water cooling system. The host machine is as follow:

    Machine’s Control section is focused on the Electrical main control section. The whole machine’s optical components are focused on the optical main beam and inside the square head through the complete optical design. The integrated water chiller provides a circulation water cooling system for the machine during working. CO2 Dynamic Laser Marking Machine mainly includes the following parts:

    ► Optical System
    ► Water Cooling System
    ► Electrical Control System
    ► IPC & Marking Motion Card
    ► Self-developed Control Software
    ► Exhausting System


    Parameter of CO2 Dynamic Laser Marking Machine


    ModelRF-HB180RF-HB250
    Max.Marking Area

    800x800mm

    (800x600mm for Paper Cut)

    1500x1500
    Laser power≥180w≥275w
    Marking Speed≤7000mm/s≤10000mm/s
    Power Consumption≤ 5 kWh≤ 7kWh
    WorktableMarble Worktable/Aluminum Honeycomb Worktable
    Laser SourceRofin/Coherent CO2 metal RF Laser Tube
    Laser Wavelength10.64μm
    Laser Frequency20kHz~200kHz
    ScannerCTI America
    Repetition Precision0.01mm
    Min.Letter Size0.3mm
    System SupportWIN 7/WIN 8
    Output CompatibilityAuto CAD, Photoshop, CorelDRAW etc
    File FormatsPLT, DXP, BMP, JPG, AI etc
    Software CharacterIntegrated Function of Dotting Design, Vector Drawing, Marking, Scribing and Cutting
    Power Supply110V~380V/50Hz~60Hz
    Cooling WayCirculation of Water Cooling

    Samples


    150W 3D Dynamic CO2 Laser Marking Machine For Invitation Card Shoes Soles Leather

    150W 3D Dynamic CO2 Laser Marking Machine For Invitation Card Shoes Soles Leather
