    Energy Saving Automatic Laser Marking Machine 30W 60W Low Power Consumption

    Wood Acrylic Leather SYNRAD RF Laser Tube 30W 60W CO2 Laser Marking Machine


    Product Introduction:


    HG-HB series Co2 Laser Marking Machine adopts advanced digital high speed scan galvanometer and module design that separate laser generator and lifter, which is not only small volume, quick speed, but easily marks on big objects surface. Also, It is very easy for moving and installing on customer's automatic production line for bar code and logo flying marking.


    Products Advantages:


    1. Co2 laser marking machine adopts the imported USA Synrad Brand Metal RF tube, high speed Galvo system to enable stable laser output and high quality laser mode.
    2. Co2 laser marking machine for its fast marking speed, good marking effect and high efficiency to meet the demand of mass production.
    3. All these factors devotes to its capacity to satisfy industrial production.


    Specifications:


    ModelHG-HB
    Wave length of laser10.64um
    Laser repetition frequency20kHz~100kHz
    Laser power30W/60W/100W
    Marking area110mm*110mm-300mm*300mm
    Laser sourceAmerican Synrad or China brand
    Laser headSINO-Galvo
    Field lensSingapore wavelength
    Control systemJCZ- Ezcad
    Working accuracy0.001mm
    Marking speed7000mm/s
    Repeated accuracy0.003mm
    Cooling waysAir cooling
    Power supply220V/50HZ/1-PH or 110v/60HZ/1PH
    Process MaterialNon-metal Materials
    Support formatPLT, BMP, DXF, JPG, TIF, AI etc
    PackageWooden case for export

    Application Materials:


    Non-metal materials, such as Acrylic, leather, ABS, Nylon, PES, PVC, Makrolon, wood etc.


    Application Industries:


    Glass industry, package industry, sign industry, leather products industry,

    wood industry especially for LGP Engraving, Dotting,

    LGP LED panel lighting / LED ceiling / TV monitor /

    Laptop monitor LED Backlight Panels etc.
